Description
The AICHI E-Series Scissor Lifts can easily be used for multiple purposes between facilities maintenance, construction, plumbing, painting, and more. The E-Series Scissor Lifts can fit through a standard doorway and can reach working heights of 25, 26, 32, and 38 feet.
Specifications
Manufacturer
Toyota Material Handling
Model
SV2632E
Year
2026
Category
Forklifts / Lift Trucks
Subcategory
Aichi Scissor Lift
Overall Length ft in (m)
7' 6.6" (2.3)
Overall Length with Fold-down Guardrails Folded ft in (m)
8' 2" (2.49)
Overall Width in (cm)
31.9 (81)
Overall Height ft in (m)
7' 7.4" (2.33)
Overall Height with Fold-down Guardrails Folded ft in (m)
6' 6.2" (1.99)
Turning Radius (Outside) in (m)
88.5 (2.25)
Ground Clearance (Center of Wheelbase) in (cm)
5.1 (13)
Ground Clearance (w/ Pothole Protectors Deployed) in (cm)
0.787 (2)
Wheelbase in (m)
73.9 (1.88)
Tire Size (Diameter x Width) in (cm)
16x4.9 (40.6x12.5)
Tread (Front and Rear) in (cm)
26.9 (68.5)
Platform Working Height ft (m)
32 (9.75)
Platform Height (Lowered) in (m)
47.8 (1.22)
Platform Height (Elevated) ft (m)
26 (7.92)
Platform Inner Length in (cm)
86.7 (220)
Platform Extension Length in (cm)
35.4 (90)
Platform Inner Width in (cm)
26.8 (68)
Platform Railing Height in (cm)
43.3 (111)
Vehicle Weight US/CA lb (kg)
4630 (2100)
Ground Bearing Pressure psi
90
Platform Capacity at Lift Height lb at in (kg at m)
500 @ 306 (227 @ 7.77) / 800 @ 236 (363 @ 6.0)
Platform Extension Capacity lb (kg)
250 (113)
Scissor Link Stages #
4
Platform Lift/Lower Time sec
33/37
Max Travel Speed (Lowered) mph (km/h)
2.8 (4.5)
Max Travel Speed (Elevated) mph (km/h)
0.5 (0.8)
Voltage V
24
Drive System
Brushless Dual AC Motors
Gradeability deg (%)
14° (25%)
Tire Type
Solid
Maximum Drive Height
Fully Elevated
