Description
The TMT 55 XT 4W truck-mounted forklift is designed for single-side loading for logistics professionals, particularly those working in the construction sector. It enables you to deliver materials to customers who don't have loading/unloading bays, or with sites not accessible by paved roads. The bi-directional mode means you can move the forklift sideways, which is useful when you have to park the lorry on the side of the road or alongside a wall or other lorry. Designed to last, the TMT 55 XT 4W is built using robust components, for maximum cost effectiveness and minimum payload.
Specifications
Manufacturer
Manitou
Model
TMT 55 XT 4W Y ST5
Year
2026
Category
Forklifts / Lift Trucks
Subcategory
Truck Mounted Forklifts
Reach out equipment
Telescopic boom
Power source
Diesel
Operator type
Sitting
Max capacity
5512 lb
Load center of gravity
24 in
Load distance, centre of drive axle to fork
-20 in
Wheelbase
65 in
Service weight
6415 lb
Tyres type
Pneumatic
Number of front wheels / rear wheels
2 / 1
Drive wheels (front / rear)
2 / 1
Front wheel gauge
86 in
Lifting speed (laden / unladen)
0.82 ft/s / 0.89 ft/s
Lowering speed (laden / unladen)
0.95 ft/s / 1 ft/s
Type of drive control
Mechanical
Working hydraulic pressure for attachments
3916 PSI
Oil flow rate for attachments
12 US gpm
Measured/guaranteed mean noise level at the ear of the operator
105 dB
Dimensions of front wheels
10x16,5
Dimensions of rear wheels
31x15,5-15
Mast/fork carriage tilt, forward
100 °
Mast/fork carriage tilt, backward
12 °
Height telescopic boom lowered
89 in
Mast free lift
57 in
Max lifting height
134 in
Height telescopic boom extended
154 in
Height of overhead guard (cabin)
93 in
Height of low overhead guard (option)
85 in
Seat height/stand height
55 in
Overall length
111 in
Length to face of forks
63 in
Overall width
97 in
Forks section / width / length
2 in x 4 in x 48 in
Fork carriage ISO 2328 (class/form) A/B
FEM 2A
Fork carriage width
50 in
Distance between support arms
49 in
Distance between wheel arms/loading surfaces
60 in
Ground clearance at centre of wheelbase
11 in
Aisle Width for pallets 1000 x 1200 crossways
79 in
Aisle width for 800 x 1200 pallet lengthways
77 in
Turning radius
117 in
Internal turning radius (over tyres)
2 in
Service brake
Hydraulic brakes by loss of pressure
