Description
The MLT/MLT-X 850-145 V+ is designed to meet the needs of large farms, ETAs, cooperatives, agro-industry as well as the recycling and environmental sector.With a capacity of 5 tons and maximum lifting height of 24'11" (7.60 m), this machine can handle high capacity attachments and a very high hydraulic working speed. The MLT 850 has the best work rate in its category: +18% compared to the competition, that is to say 2 more loaded semi-trailers per hour.Maximum productivity: the MLT 850 offers more than 600 Nm of torque, with a pulling force of more than 9160 daN (+20% compared to the competition). The high speed of movement provided by the 53 gpm (200 l/min) LSU pump is complemented by a bucket breakout force of over 8670 daN (+32% compared to the competition).Effortless comfort: As with the entire NewAg XL range, the MLT 850 has the quietest cab on the market with only 69 dBA to reduce your fatigue. The cabin access has been optimized with two Easy-step steps combined with under-door lighting make getting in and out even safer, day or night.Unmatched cost effectiveness: the MLT 850 is coupled with a range of services offered and adapted to your use and boasts a 4% reduction in maintenance costs as well as the lowest total cost of ownership in its category with 8% less than the competition. In addition, the energy efficiency of this machine allows you to consume 20% less fuel than the competition.
Specifications
Manufacturer
Manitou
Model
MLT 850-145 V+
Year
2026
Category
Forklifts / Lift Trucks
Subcategory
Forklift Trucks
Max capacity
11020 lb
Breakout force with bucket
8670 daN
Unladen weight (with forks)
23766 lb
Tilt-down angle
132 °
Tilt-up angle
12 °
Drive wheels (front / rear)
2 / 2
Steering wheels (front / rear)
2 / 2
Lifting
6.60 s
Lowering
4.90 s
Extension
6.30 s
Retraction
5.70 s
Crowd
4.20 s
Dump
3.10 s
Transmission type
Continuously variable transmission
Gearbox
M-Vario Plus
Max travel speed (may vary according to applicable regulations)
25 mph
Differential lock
Limited slip differential on front and rear axles
Parking brake
Automatic negative parking brake
Service brake
Oil-immersed multi-discs braking on front & rear axles
Hydraulic pump type
Variable displacement pump
Hydraulic flow - Pressure
53 US gpm - 3916 PSI
Flow sharing distributor
Standard
Noise at driving position (LpA) tested following NF EN 12053 norm
69 dB
Noise to environment (LwA)
105 dB
Vibration on hands/arms
< 2.50 m/s²
Tractor homologation
Tractor homologation
Cab certification
Cabin ROPS - FOPS level 2
Controls
JSM
Hydraulic tank capacity
37 US gal
Fuel tank
38 US gal
Diesel Exhaust fluid (AdBlue® type)
6 US gal
Consumption calculated according to EN 16796-4 standard
2 US gph
Maximum outreach
14 ft 11 in
Max lifting height
24 ft 11 in
Reach at Max height
2 ft 11 in
Ground clearance
1 ft 6 in
Wheelbase
9 ft 8 in
Overall length to carriage (with hitch)
18 ft 3 in
Overall length to carriage (without hitch)
18 ft 2 in
Front overhang
5 ft 1 in
Overall width
8 ft 2 in
Overall cab width
3 ft 3 in
Overall height
8 ft 6 in
External turning radius (over tyres)
13 ft 3 in
Standard tires
Alliance - A580 - 500/70 R24 164A8
Engine brand
Yanmar
Engine norm
Stage V / Tier 4 Final
Max fuel sulphur content
1000 ppm
Engine model
4TN107FHT-5SMUF
Number of cylinders - Capacity of cylinders
4 - 279 in³
I.C. Engine power rating / Power
141 Hp / 105 kW
Max torque / Engine rotation
444 ft/lbs @1500 rpm
Drawbar pull (Laden)
9160 daN
Engine cooling system
3 radiators water + intercooler + transmission oil
