Description
Drive your forklift easily whatever the type of ground. The concept of large wheels at the front combined with hydrostatic transmission give the MSI models excellent flexibility of use. With a capacity of 4 tons, the MSI 40 is particularly manoeuvrable and flexible of use. Its stability and versatility make it at home in warehouses as well as in stabilised or unstabilised outdoor storage yards.
Specifications
Manufacturer
Manitou
Model
MSI 40 ST5
Year
2026
Category
Forklifts / Lift Trucks
Subcategory
Forklift Trucks
Power source
Diesel
Operator type
Sitting
Max capacity
8818 lb
Load center of gravity
20 in
Load distance, centre of drive axle to fork
27 in
Wheelbase
82 in
Service weight
15388 lb
Weight on front axle (laden)
20382 lb
Weight on front axle (Unladen)
7077 lb
Tyres type
Pneumatic
Number of front wheels / rear wheels
2 / 2
Number of drive wheels
2
Front wheel gauge
56 in
Rear wheel gauge
45 in
Travel speed (laden / unladen)
12 mi/h-12 mi/h
Lifting speed (laden)
2 ft/s
Lowering speed (laden)
2 ft/s
Drawbar pull (Laden)
3103 daN
Gradeability (laden)
34 %
Type of drive control
Electronic
Oil flow rate for attachments
12 US gpm
Sound level at the driver's ear according to DIN 12 053
81 dB
Dimensions of front wheels
315/70 R22,5 KMAX
Dimensions of rear wheels
225/75 R15 XZM
Height of overhead guard (cabin)
96 in
Seat height/stand height
56 in
Height of towing bar (coupling height)
24 in
Overall length
177 in
Length to face of forks
130 in
Overall width
68 in
Forks section / width / length
2 in x 6 in x 47 in
Fork carriage ISO 2328 (class/form) A/B
3A
Fork carriage width
66 in
Ground clearance below mast
7 in
Ground clearance at centre of wheelbase
9 in
Aisle Width for pallets 1000 x 1200 crossways
195 in
Turning radius
113 in
Engine brand / model
Deutz / TCD 2,9L
Engine power according to ISO 1585
55 kW
Rated speed
2200 rpm
Number of cylinders / Capacity of cylinders
4 - 177 in³
Service brake
Hydraulic
Working hydraulic pressure for attachments
3336 PSI
